Fujitsu Server PRIMERGY TX1330 M1 User Manual

TX1330 M1 Upgrade and Maintenance Manual 187
Expansion cards and backup units
9.4.5 Replacing the TFM
9.4.5.1 Preliminary steps
Ê "Locating the defective server" on page 43
Ê "Disabling BitLocker functionality" on page 69
Ê "Shutting down the server" on page 46
Ê "Disconnecting the server from the mains" on page 46
Ê Remove all external cables from the expansion card to be removed.
Ê "Getting access to the component" on page 47
Ê "Removing the fan module" on page 151
9.4.5.2 Removing the defective TFM
Ê Remove the depending expansion card as described in section "Removing
an expansion card" on page 180.
Ê Disconnect the FBU adapter cable as described in section "Disconnecting
the FBU adapter cable from the TFM" on page 200.
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH1 / (+) No. 1 screw driver

Fujitsu Server PRIMERGY TX1330 M1 Specifications

General

Memory Slots	4
Form Factor	Tower
Chipset	Intel C226
Processor Sockets	1
Processor	Intel Pentium, Intel Celeron
RAID Support	RAID 0, 1, 5, 10
Drive Bays	8 x 3.5-inch
Operating System Support	Windows Server, Red Hat, SUSE, VMware
