Fujitsu Server PRIMERGY TX1330 M1 User Manual

108 Upgrade and Maintenance Manual TX1330 M1
Power supply
6.3.1.3 Installing a hot-plug power supply unit
Figure 35: Installing a power supply unit
Ê Push the power supply unit into its slot (1) as far as it will go until the locking
latch snaps in place (2).
V CAUTION!
Ensure that the power supply unit properly engages in its slot and is
locked in position in order to prevent it from sliding out of the chassis
during transportation.
Ê If applicable, fold down the handle on the power supply unit.
6.3.1.4 Concluding steps
Ê For the added power supply unit: "Connecting the server to the mains" on
page 67

Fujitsu Server PRIMERGY TX1330 M1 Specifications

General

Memory Slots	4
Form Factor	Tower
Chipset	Intel C226
Processor Sockets	1
Processor	Intel Pentium, Intel Celeron
RAID Support	RAID 0, 1, 5, 10
Drive Bays	8 x 3.5-inch
Operating System Support	Windows Server, Red Hat, SUSE, VMware
