Fujitsu Server PRIMERGY TX1330 M1 User Manual

TX1330 M1 Upgrade and Maintenance Manual 241
Accessible drives
12.3 Removing accessible drives
12.3.1 Preliminary steps
Ê "Disabling BitLocker functionality" on page 69
Ê "Locating the defective server" on page 43
Ê "Removing backup and optical disk media" on page 72
Ê "Verifying and configuring the backup software solution" on page 73
Ê "Shutting down the server" on page 46
Ê "Disconnecting the server from the mains" on page 46
Ê "Getting access to the component" on page 47
Ê "Removing the rack front cover" on page 52 (rack server) or "Removing the
front cover" on page 56 (tower server)
I The front cover only needs to be removed in order to remove or install
accessible drive dummy covers.
12.3.2 Removing an accessible drive
Ê Disconnect all cables from the accessible drive.
Ê Press out on the locking latch to disengage the accessible drive locking bar
(see figure 146).
Ê Fold up the accessible drive locking bar.
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver (for removing the rack front cover)
Other procedures: tool-less
