Ê If applicable, reconfigure your network settings in the operation system
according to the original configuration of the replaced controller (expansion
card or onboard).
I Configuration of network settings should be performed by the
customer.
For further information, please refer to section "Note on network
settings recovery" on page 182.
Ê If applicable, "After replacing / upgrading LAN controllers" on page 94
9.4.4 Replacing the riser card
9.4.4.1 Preliminary steps
Ê "Locating the defective server" on page 43
Ê "Disabling BitLocker functionality" on page 69
Ê "Shutting down the server" on page 46
Ê "Disconnecting the server from the mains" on page 46
Ê Remove all external cables from the expansion card installed in the riser
card slot.
Ê "Getting access to the component" on page 47
Ê "Removing the fan module" on page 151
9.4.4.2 Removing the defective riser card
Ê Remove the expansion card from the riser card slot as described in section
"Removing an expansion card" on page 180.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
To Next Page
