TX1330 M1 Upgrade and Maintenance Manual 311
Cabling
16.3 Replacing the intrusion switch cable
16.3.1 Preliminary steps
Ê "Locating the defective server" on page 43
Ê "Shutting down the server" on page 46
Ê "Disconnecting the server from the mains" on page 46
Ê "Getting access to the component" on page 47
Ê "Removing the rack front cover" on page 52 (rack server) or "Removing the
front cover" on page 56 (tower server)
16.3.2 Removing the defective intrusion switch cable
Figure 211: Disconnecting the intrusion switch cable
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver

Fujitsu Server PRIMERGY TX1330 M1 Specifications

General

Memory Slots	4
Form Factor	Tower
Chipset	Intel C226
Processor Sockets	1
Processor	Intel Pentium, Intel Celeron
RAID Support	RAID 0, 1, 5, 10
Drive Bays	8 x 3.5-inch
Operating System Support	Windows Server, Red Hat, SUSE, VMware
