334 Upgrade and Maintenance Manual TX1330 M1
Appendix
17.4 Minimum startup configuration
If the server does not start up or other problems occur, it may be necessary to
take the system down to its most basic configuration in order to isolate the
defective component.
The minimum startup configuration consists of the following components and
cables:
Ê "Shutting down the server" on page 46
Ê "Disconnecting the server from the mains" on page 46
Ê Take the system down to its minimum startup configuration.
Ê "Connecting the server to the mains" on page 67
Ê Connect a keyboard, mouse and display to the server.
Ê "Switching on the server" on page 68
Field Replaceable Units (FRU)
Component Notes
System board no TPM, UFM or expansion cards installed
CPU with CPU heat sink
1 memory module installed in DIMM slot 1A
Front panel module
Power supply unit
Table 9: Minimum startup configuration - components
Cable Notes
Front panel cable
Power cable
Table 10: Minimum startup configuration - cables

Fujitsu Server PRIMERGY TX1330 M1 Specifications

General

Memory Slots	4
Form Factor	Tower
Chipset	Intel C226
Processor Sockets	1
Processor	Intel Pentium, Intel Celeron
RAID Support	RAID 0, 1, 5, 10
Drive Bays	8 x 3.5-inch
Operating System Support	Windows Server, Red Hat, SUSE, VMware
