200 Upgrade and Maintenance Manual TX1330 M1
Expansion cards and backup units
9.5.4 Removing an FBU
V CAUTION!
Do not throw FBUs into the trash can. Batteries must be disposed of in
accordance with local regulations concerning special waste.
For further safety information, please refer to section "Environmental
protection" on page 41.
9.5.4.1 Preliminary steps
Ê "Shutting down the server" on page 46
Ê "Disconnecting the server from the mains" on page 46
Ê "Getting access to the component" on page 47
Ê "Removing the fan module" on page 151
9.5.4.2 Disconnecting the FBU adapter cable from the TFM
Figure 116: Disconnecting the FBU adapter cable from the TFM
Ê Disconnect the FBU adapter cable from the TFM.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
