22. SETTINGS MENU
22-12
5 Keys of both the Radar Con-
trol Unit and chart radar
Control Unit
Operate each key. The pressed key lights in
light blue.
6 Trackball module Check the trackball module of a Control Unit:
1) Spin the scrollwheel and rotate the track-
ball. The indication above the operated
control shows the setting value.
2) Push each button. The window above a
pushed button lights in light blue.
3) Push the scrollwheel. The window above
the wheel lights in light blue.
7 [Buzzer ON] button Click the [Buzzer ON] button to sound the
buzzer. The buzzer sounds and the button
flashes (in red). Click the button again to can-
cel.
8 [Contact Output] button Click the [Contact Output] button to output the
Alarm output contact signal from the Proces-
sor Unit. Click the button again to cancel.
No. Name Description
