1. OPERATIONAL OVERVIEW
1-35
Chart for Radar mode
VRM2 OFF (No change)
EBL1 ON (No change)
EBL2 OFF (No change)
Presentation mode North-up TM
Note: Head-up RM with no heading or position data.
Off Center The ship’s position is put beyond 75% of the range scale.
Trail Trail time: 6 min, Trail mode: True-G
Past POSN OFF
Lost TGT OFF
TT ACQ No change
Note: TT OFF with no heading data.
Vector Vector time: 6 min, Vector reference: REL
AZ1, AZ2 (acquisition
zone)
OFF
AIS DISP ALL
Note: FUNC OFF with no heading or position data.
Association TT (>)
CPA/TCPA CPA: 2 NM, TCPA: 12 min
AIS CPA AUTO ACT ALL
Display mode RADAR
MAP (Radar map) No change
Route No change
Alert AZ1/AZ2: OFF, Lost TGT: OFF
Antenna connection status No change
RANGE RING OFF
PI LINE PI1 to PI6: OFF
Number of PI line, mode, bearing range truncate: No
change
SPD (Own Ship Sensor
Setting)
Stabilization Mode: Bottom*
Sensor Type: GPS*
Sensor Setting: No change (System or Local)
*: These settings can not be applied, the settings are
changed according to the priority order of SPD.
Item Settings
[Route Information] menu
Route information page unit of “XTD” m
[System Sensor Settings]/[Local Sensor Settings] menu
SPD page Stabilization Mode Bottom
[Other Sensor Settings] menu
Other Sensor page Wind m/s
[Basic Setting] menu
Items Settings
To Next Page
