2. RADAR, CHART RADAR OPERATION
2-11
Adjusting these features from the [CUSTOMIZE ECHO] menu changes the original
function key settings. To restore the original settings for a particular customize option,
it is necessary to select the default setting. For this reason, we recommended that you
use the user-programmable presets when frequent adjustment of the radar image is
necessary.
* Manual
8 PULSE
9 CONDITION
INT
REJECT
ECHO
STRETCH
ECHO
AVERAGE
NOISE
REJECT
AUTO
SEA
AUTO
RAIN
VIDEO
CONTRAST
OCEAN 2 2 3 ON OFF* OFF* 3-B
CANAL 2 OFF OFF OFF OFF* OFF* 2-B
BERTHING 2 OFF OFF OFF OFF* OFF* 2-B
CONGESTION 2 OFF 2 OFF OFF* OFF* 1-B
ROUGH SEA 2 OFF 2 OFF OFF* OFF* 2-A
HARD RAIN 2 OFF OFF OFF OFF* ON 2-A
CUSTOM1 2 OFF OFF OFF OFF* OFF* 1-B
CUSTOM2 2 2 1 OFF OFF* OFF* 2-B
0.5 NM 0.75 NM 1.5 NM 3 NM 6 NM 12, 24 NM
OCEAN S2 M1* M1 M3 L L
CANAL S1 S2 M1 M2 M3 L
BERTHINGS1S1S2M1M3 L
CONGESTIONS1S2S2M1M2 L
ROUGH SEA S1 S1 S2 M1 M2 M3
HARD RAIN S1 S2 S2 M1 M2 L
CUSTOM1 S1S2S2M1M1 L
CUSTOM2 S2 S2 M1 M2 M3 L
STC
ANT.
HEIGHT
LOW
LEVEL
ECHO
STC
RANGE
GAIN SEA RAIN
OCEAN Set at in-
stallation
0 ±0 80 MAN-30 MAN-0
CANAL 0 ±0 80 MAN-30 MAN-0
BERTHING 0 ±0 80 MAN-30 MAN-0
CONGESTION 0 ±0 80 MAN-30 MAN-0
ROUGH SEA 0 ±0 80 MAN-30 AUTO
HARD RAIN 0 ±0 80 AUTO MAN-0
CUSTOM1 0 ±0 80 MAN-30 MAN-0
CUSTOM2 0 ±0 80 MAN-30 MAN-0
