Prepare the System for Use
3-50 Vivid S70 / S60 – User Manual
BC092760-1EN
01
To ensure safety while moving the system
1. Ensure that the keyboard console is in central-locked
position.
2. Proceed cautiously when crossing door or elevator
thresholds. Grasp the front handle grips and push or pull, or
use the rear handle bar for pushing the system. Do not
attempt to move the system using cables or probe
connectors. Take extra care while moving the system on
inclines. Do not hang or lean body weight on the handles.
3. Ensure that the system does not strike the walls or door
frames.
4. Ensure that the pathway is clear, and probe cables are
secure not to catch onto anything in the path (including
wheels and feet)..
5. Move the system slowly and carefully. Limit the movement
to slow careful walk.
Ensure that the hands of the patient are away from the console
while moving the system or keyboard console.
The system weight approximately 75 Kg. To avoid possible
injury or equipment damage mobilizing handles are provided.
The rear handle should only be used for pushing the system,
not for pulling, The system might become unstable when hitting
an obstacle while pulled with the rear handle.
To minimize the risk of system tipping and avoid possible injury
and equipment damage, make sure to follow these
recommendations when moving the system on inclines:
• Avoid ramps that are steeper than 10 degrees.
• Utilize additional care and personnel when moving on a
steep incline (>5 degrees).
• Ensure the main display arm and Control panel are in
locked position.
