Storing images and cineloops
Vivid S70 / S60 – User Manual 10-7
BC092760-1EN 01
Storing images and cineloops
Images and cineloops that are stored during a current
examination are displayed as thumbnails on the clipboard.
When an image is stored, all the additional information that is
displayed is saved with it (e.i. probe and application selected,
image setting, annotations or measurements).
The image archive is set by the dataflow selected (see
page 10-3 about available dataflows).
In addition, stored images and cineloops can be saved to a
removable media in the standard formats JPEG, MPEG, AVI,
HDF and DICOM (see page 10-9).
Storing an image
Images are displayed chronologically on the clipboard.
1. While scanning in any mode, press Freeze.
2. With the trackball, scroll through the cineloop and select the
required image.
3. Press Store.
The image is stored and a thumbnail is displayed on the
clipboard.
Do not use the internal harddrive for long-term image storage.
External storage media or network-based server solution is
recommended for image long-term archive.
If working off-line with a dataflow pointing to a DICOM server,
the images stored during the examination may have to be
manually resent in the DICOM spooler when reconnecting the
system. Resend all jobs that are failed or on hold.
