Image Optimization
5-44 Vivid S70 / S60 – User Manual
BC092760-1EN
01
Vascular/Abdominal Contrast Imaging
NOTE: This system is designed for compatibility with commercially
available contrast agents. Because the availability of these
agents is subject to government regulation and approval,
product features intended for use with these agents may not be
commercially marketed nor made available before the contrast
agent is approved for use. Advanced contrast features are only
enabled on systems for delivery in countries or regions where
the agents are approved for use or for investigational or
research use.
Vascular Contrast is intended for visualization of ultrasound
contrast agents in large vessels (e.g. carotid artery and femoral
artery).
The Vascular Contrast application works with the 9L-D probe.
Abdominal Contrast optimized to visualize contrast agents in
abdominal organs.
The Abdominal Contrast application works with the C1-6-D
probe.
NOTE: The Vascular and Abdominal Contrast applications require the
Vascular/Abdominal Contrast option enabled.
Quantification
Quantification enables the user to perform the following
analysis:
• Time-Intensity analysis: allows instant time-intensity
calculation from up to eight regions of interest.
• Curve fitting analysis: for observing and quantifying
increase or decrease in contrast intensity according to a
predefined curve fit template.
• Arbitrary Anatomical M-Mode (Curved and Straight):
M-Mode applied to intensity data calculates and color-codes
tissue along a path drawn by the operator vs. time.
The Vascular and Abdominal Contrast applications may not be
available on your system.
