Scan Assist Pro
Vivid S70 / S60 – User Manual 5-59
BC092760-1EN 01
Scan Assist Pro
Scan Assist Pro provides an automated examination script that
guides you through an examination step-by-step. The system
automatically invokes the correct mode and imaging
parameters, advances to the next step in an examination,
annotates the image, initiates measurements, and assigns the
measurements to the worksheet/report.
Scan Assist Pro overview
Figure 5-23. Scan Assist Pro window
1. Protocol name
Completed steps/number of steps
2. Step instruction area
3. Protocol steps
Check mark: completed step
Frame: current step (The frame is green
when the Protocol is active or yellow
when it is paused.)
4. This column indicates the scanning
mode or when a measurement needs to
be made.
5. This column indicates the action to
move the Protocol to the next step.
6. Navigation: Stop, Pause/Continue the
Protocol.
