Connectivity
Vivid S70 / S60 – User Manual 10-39
BC092760-1EN 01
Dataflow selection
Select a dataflow from the Archive screen (see Figure 10-5 on
page 10-15) or configure the system with a default dataflow
from the Configuration management package as described
below.
Default dataflow selection
1. Press Utility/Config on the Touch panel and log on as
administrator if required.
2. Select the Connectivity category and Dataflow subgroup.
The Dataflow sheet is displayed (see Figure 10-21).
3. Select the desired dataflow in the Dataflow pull-down menu
and check the option Default.
4. Press Config to exit the Configuration management
package.
Figure 10-21. Default dataflow
In this scenario the data is transferred from the Vivid S70 / S60 to a dedicated EchoPAC Software Only
workstation over the Ethernet (either in a peer-to-peer connection with a crossover cable, or in a network).
The database from the EchoPAC Software Only is used as the master and images are stored directly to the
EchoPAC Software Only internal harddrive. In this configuration the system is just an intermediate
acquisition system which after completion of a study, will not contain any patient information, measurements
or images.
Up to four systems can be connected to one EchoPAC Software Only if the workstation has the EchoPAC
Share option enabled. A Vivid S70 / S60 using the 203 software can only connect to an EchoPAC Software
Only also using the 203 software. Older version Vivid S70 / S60 can connect via EchoPAC Share if
compatible with Sybase 16. Please contact your local GE representative to update software for Sybase 16
compatibility if required.
System and EchoPAC Software Only in a direct connect environment
1. Select a dataflow
2. Default option for the selected dataflow
