Worksheet
Vivid S70 / S60 – User Manual 8-95
BC092760-1EN 01
Using the Worksheet
1. Press Worksheet on the Control panel.
2. Select the Measurement type.
3. To browse through the measurements, select Page Up or
Page Down or adjust Page Change.
To select a type of value
1. Select the relevant cell in the Mth (Method) column.
A pop-up menu is displayed showing the different options
available.
Figure 8-55. Value options
2. Select the required option.
The value is updated accordingly.
To exclude or include measurements
One or more measurement values from a set of measurements
for a parameter can be excluded when doing average
calculation.
1. Place the cursor over the measurement to exclude.
2. Press Update Menu.
3. Select Exclude value/Include value from the context
menu.
1. Average of the measurements taken
2. Maximum measurement
3. Minimum measurement
4. Last measurement that was taken
