4D and Multi-plane Modes
6-28 Vivid S70 / S60 – User Manual
BC092760-1EN
01
4D-Mode controls
Control panel
4D Gain (Active Gain rotary)
4D, 4D Color Affects the transparency of the volume rendering. Too much 4D Gain applied will
take away structures, too little will leave opaque “Gray clouds” in the ventricle.
Zoom (4D Zoom prepare)
4D, 4D Color Enters 4D Zoom prepare acquisition:
Enables 4D Zoom prepare acquisition displaying a biplane screen with an
adjustable zoom ROI in the azimuth and elevation planes. After adjustment of the
ROI, press 4D to acquire 4D data for the defined ROI (see page 6-13).
Layout
4D, 4D Color Toggles the display between different screen layouts.
Update Menu
4D, 4D Color Depending on the situation:
• Toggles between 4D Color Flow Prepare mode and 4D Color Flow acquisition.
• Toggles between 4D/4D Color Flow Zoom mode and 4D/4D Color Zoom prepare
mode.
