Measurements and Analysis
8-10 Vivid S70 / S60 – User Manual
BC092760-1EN
01
Measurements on protocol images
When performing measurements on images acquired in a
protocol, the measurement results will be associated with the
protocol level of the image. Average values will be calculated for
each protocol level.
For example you may measure LVOT Diam for images acquired
outside protocol and for images on each level of an
Exercise 2x4 protocol, leading to the following results in
worksheet:
Example results
Parameter Value Method m1 m2
LVOT Diam 1.0 cm Average 1.1 0.9
LVOT Diam, Rest 1.1 cm Average 1.0 1.2
LVOT Diam, Peak 1.2 cm Average 1.2
Measurement results associated with a stress level will not be
updated if the image is moved to another stress level at a later
time. Images should be correctly placed in the protocol before
performing measurements.
