Multi-plane mode
Vivid S70 / S60 – User Manual 6-45
BC092760-1EN 01
V-Planes
In Bi-plane mode, rotates scan plane 2, so that it has the same angle as scan
plane 1. The scan plane 2 can then be tilted.
Quick Rotate
Rotates all scan planes to pre-defined angles.
Angle 1 / Angle 2
• Angle 1: adjusts the angle between the scan planes 2 (white) and scan plane 1
(yellow). Scan plane 2 is rotated around the crossing line between the scan
planes.
• Angle 2: adjusts the angle between the scan planes 3 (green) and scan plane 1
(yellow). Scan plane 3 is rotated around the crossing line between the scan
planes.
These controls are identical to the Trackball controls Angle 1 and Angle 2.
Rotate
Rotates all scan planes around the crossing line between the scan planes.
Bird’s View / Medium / Large
Starts 4D Acquisition: sets the volume size for the 4D acquisition (see page 6-7).
4D Zoom prepare
Enables 4D Zoom prepare acquisition displaying a biplane screen with an
adjustable zoom ROI in the azimuth and elevation planes. After adjustment of the
ROI, press 4D to acquire 4D data for the defined ROI (see page 6-13).
Right Invert
In Transesophageal Bi-plane mode Live only: mirrors the image on the right hand
side.
