GE Vivid S60

Advanced cardiac measurements and analysis
Vivid S70 / S60 – User Manual 8-29
BC092760-1EN 01
Apex Correct Wrong
1. Correct position of the Apex
point.
2. The apex point is placed too
high. The ROI is extending
beyond the epicardium.
1. Correct position of the Apex
point.
2. The upper right border of the
ROI is way too much into the
chamber cavity.
