GE Vivid S60

Measurements and Analysis
8-102 Vivid S70 / S60 – User Manual
BC092760-1EN
01
Annulus perimeter /
MV Annulus Perimeter
7.8 - 17.7 cm 10% Accuracy w/o editing: 15%
Anterior/Posterior Leaflet
Billowing
0.0 - 7.8 mm max (10%, 3 mm) Accuracy w/o editing: 5 mm
Anterior Closure Line Length
3D
2.6 - 5.9 cm 20% Accuracy w/o editing: 25%
Anterior Leaflet Angle 4 - 30° 10° Accuracy w/o editing: 15°
Anterior Leaflet Area
2.5 - 12.1 cm
2
max (10%, 1.0 cm
2
)
Accuracy w/o editing: 20%
Anterior Leaflet Length /
MV Ant Leaflet Len
1.4 - 3.6 cm max (10%, 3 mm) Accuracy w/o editing: 20%
A-P Diameter /
MV A-P Diam
1.8 - 5.0 cm 10% Accuracy w/o editing: 15%
Commissural Diameter 2.9 - 5.7 cm 10% Accuracy w/o editing: 15%
Inter-Trigonal Distance /
Inter-Trigonal Dist
1.9 - 4.1 cm 10% Accuracy w/o editing: 20%
Mitral Annular Excursion 1.9 - 14.1 mm max (10%, 3 mm) Accuracy w/o editing: 5 mm
Mitral-Aortic Angle 120 - 139° 10% Accuracy w/o editing: 20°
Non-Planar Angle 126 - 171° 10% Accuracy w/o editing: 20°
Orifice Area
0.0 - 1.4 cm
2
max (10%, 0.2 cm
2
)
Accuracy w/o editing:
1.0 cm
2
PM-AL Diameter /
MV PM-AL Diam
2.9 - 5.9 cm 10% Accuracy w/o editing: 15%
Posterior Closure Line Length
3D
2.6 - 6.4 cm 20% Accuracy w/o editing: 25%
Posterior Leaflet Angle 5 - 56° 10° Accuracy w/o editing: 15°
Posterior Leaflet Area
2.6 - 16.7 cm
2
max (10%, 1.0 cm
2
)
Accuracy w/o editing: 20%
Posterior Leaflet Length /
MV Post Leaflet Len
0.8 - 2.5 cm max (10%, 3 mm) Accuracy w/o editing: 20%
Tenting Area
0.3 - 4.1 cm
2
max (10%, 0.5 cm
2
)
Accuracy w/o editing:
1.0 cm
2
Tenting Height /
MV Tenting Height
0.2 - 1.4 cm max (10%, 3 mm) Accuracy w/o editing: 5 mm
Tenting Volume 0.2 - 11.1 ml max (10%, 1 ml) Accuracy w/o editing: 1.5 ml
4D Auto AVQ (Aortic Annulus)
Area
3.3 - 5.2 cm
2
10% Accuracy w/o editing: 30%
Diameter 2.1 - 2.7 cm 10% Accuracy w/o editing: 15%
Measurement Range Accuracy Comments
