Connectivity
Vivid S70 / S60 – User Manual 10-37
BC092760-1EN 01
Dataflow examples
Stand-alone system
Acquisition:
System dataflow: LocalArchive-Int.HD
Review:
System dataflow: LocalArchive-Int.HD
The local database is used for patient archiving. Images are stored to internal harddrive.
System and Workstation in a network environment
Acquisition:
System dataflow: RemoteArch-Remote HD
Review:
Workstation dataflow: RemoteArch-Remote HD
In this scenario the Vivid S70 / S60 is configured to work with an ImageVault patient demographics and
image server in a network environment. Images are first saved on the local image buffer on the system and
transferred to the server when saving the examination.
