Structured Findings
Vivid S70 / S60 – User Manual 11-17
BC092760-1EN 01
Creation of a tab sheet
The following procedure describes how to create a tab sheet in a
tab page.
Figure 11-8. New tab sheet
1. Make sure that the tab page is selected and press Add.
A new entry is created in the tab page. The new entry is by
default a tab sheet ( ).
2. With the new entry selected, follow the following steps:
• Enter a name in the Label field (tab name).
• Enter a description in the Findings text field.
If required:
• Enter the appropriate codes.
NOTE: To enter several codes separate each code by a space.
1. Configuration window
2. Structured findings window
