Users and Security
Vivid S70 / S60 – User Manual 12-13
BC092760-1EN 01
To define the LDAP properties:
1. Enter the configuration properties.
2. Press Connect to test the connection and enter a valid user
name and password for the LDAP server in the dialog that
appears.
3. Define group mapping for the LDAP user groups that shall
be grant users access to the system.
The user will be assigned one or more system groups according
to the group mapping and which of these LDAP groups the user
is a member of.
Figure 12-6. The Advanced LDAP configuration screen of the LDAP sheet
If the Directory Server does not support anonymous connection
for the authentication service, two step authentication is needed.
Then valid user credentials for a user with access to the
Directory Server must be entered here.
NOTE: The user credentials will be stored on the system.
Group mapping Map LDAP groups to system groups. An LDAP group can be mapped to
zero or more system groups. Several LDAP groups can be mapped to
the same system group.
Definition
