Customize Configuration
12-18 Vivid S70 / S60 – User Manual
BC092760-1EN
01
Global imaging settings
The followings settings can be configured:
Parameter Description
Cineloop store • Time before/after heart cycle: sets the total storage time span
of the cineloop in ECG mode.
• Preview loop before store: when selected enable review of
cineloops before storage.
• Retrospective / Prospective
• Retrospective: store the last elapsed defined number of
cycles/seconds.
• Prospective: store the forthcoming defined number of
cycles/seconds.
Crop images In the Analysis screen, removes top and bottom of the image
when more than two images have been selected.
Doppler • Show KHz scale: when selected, displays the KHz scale on the
left side of the Doppler spectrum (see Figure 5-9 on page 5-19).
• PW/CW: Link baseline and gain controls: when selected,
baseline and gain settings are preserved when toggling
between PW and CW Doppler modes.
Biopsy Guides Configure the biopsy guide zone display
Patient Info • Title bar Line 1 & 2: selects from the drop-down menu the
patient information to display on the Title bar.
• Anonymous patient: when checked, no patient information is
displayed on the Title bar.
Scan Info • Select the scan information to be displayed on the upper left
corner of the image area.
Upper Select button The upper button on the Trackball area can be configured as:
• a Select key
• a pointer
• an Image store button
• an image cursor
