Prepare the System for Use
3-20 Vivid S70 / S60 – User Manual
BC092760-1EN
01
Any devices or cables, other than those sold with the
ultrasound system, connected to the Peripheral /accessory
connector panel, or to an USB port on the system may result in
an increase in the electromagnetic emission from the system,
or a decrease in the electromagnetic immunity of the system.
Socket Signal type Device type Note
Insulated USB Universal serial bus
supporting USB 1.0
Printer Printers with external power
supply will connect here
USB - Dual socket Universal serial bus
supporting USB 2.0
Memory devices Devices without
external power
supply will connect here
DVI Digital signals only Digital monitor This is a DVI-I connector, but
there is no analog signal
transmission. Only digital
monitors can be connected.
Ethernet 1000 Base-TX
Ethernet IEEE 802.3
Network device
