GRAUPNER mc-32

43
Transmitter description - Telemetry data display
ELECTRIC AIR MODULE
RX–S QUA: 100%
RX–S ST : 100%
TX–dBm: 33dBm
RX–dBm: 33dBm
RX–SPG.:4.8 TMP
V–PACK: 10ms
CH OUTPUT TYPE:ONCE
RECEIVER
GENERAL
AIR ESC
VARIO
GPS
ELECT. AIR
0.0V 0m/3s
BAT1 0m/1s
BAT2
0.0V T2 0°C
T1 0°C
0
1L0.00
2L0.00
3L0.00
4L0.00
5L0.00
6L0.00
ALT 0m
7L0.00
0.0V 0A
ON
0.0V 0m/3s
BAT1 0m/1s
BAT2
0.0V T2 0°C
T1 0°C
0
1H0.00
2H0.00
3H0.00
4H0.00
5H0.00
6H0.00
ALT 0m
7H0.00
0.0V 0A
ON
If attached to the receiver, this display will depict the
data acquired by an Electric-Air module, No. 33620.
More details about this module can be found in the
appendix or in Internet at www.graupner.de in the
web page for the given product.
Depending on how this module is equipped with sen-
sors, this screen can permanently display the data
shown in the adjacent table.
The current voltage of up to two batteries (BAT1 and
BAT2), up to two temperature measurements (T1
and T2), current altitude with respect to the starting
location, the model’s ascent/decent rate in m/1 s and
m/3 s and, in the middle of the screen, the current
draw currently being taken from a power source.
Speed display
0
km/h
Subject to availability of the corresponding sensor,
this display visualizes the current speed over ground.
Air pressure display
0.0
Bar
Subject to availability of the corresponding sensor,
this display visualizes the current air pressure.
”lowest cell“
CELL0=0.00V
Subject to availability of the corresponding sensor,
this display visualizes the current lowest cell voltage
of the connected LiPo battery pack so as the number
of the corresponding cell.
Along the right edge of the screen is a table of alter-
nating values for cell voltages at balancer connec-
tions (L) or voltages for up to 7 attached battery cell
packs (H).
The displayed items are as follows:
Value Explanation
ON Power regulator ON
V current voltage
A current current
BAT1 /
BAT2
battery 1 or 2
ALT current altitude
m/1s m/1 s ascent/decent rate
m/3s m/3 s ascent/decent rate
100
Signal quality in % (RX-S QUA)
T1 / T2 temperature of sensor 1 or 2
L or H cell voltage of cells 1 … max. 14
L = balancer connection 1
H = balancer connection 2
Micro-copter display
0mAh
0:00
0.0V
0km/h
0
I:
Dir:
Alt: 0m
0°
0A
0m
0°
