44
Transmitter description - Telemetry data display
SENSOR 1
0.0V
0°C
SENSOR 1
If attached, this display depicts currently measured
voltage and temperature from a temperature/voltage
sensor (No. 33612 or 33613) connected to "T(EMP)1"
of the Electric-Air module (No. 33620).
SENSOR 2
0.0V
0°C
SENSOR 2
If attached, this display depicts currently measured
voltage and temperature from a temperature/voltage
sensor (No. 33612 or 33613) connected to "T(EMP)2"
of the Electric-Air module (No. 33620).
Vario
m
m
s
If attached, this display will depict the altitude
(in m) relative to location, starting location as well as
the current rate of ascent/descent (in m/s) data origi-
nating from a Vario integrated into a Electric-Air mod-
ule (No. 33620).
Speed display
0
km/h
Subject to availability of the corresponding sensor,
this display visualizes the current speed over ground.
”lowest cell“
CELL0=0.00V
Subject to availability of the corresponding sensor,
this display visualizes the current lowest cell voltage
of the connected LiPo battery pack so as the number
of the corresponding cell.
This display visualizes the data of an HoTT compat-
ible microcopter. It means from left up to right down:
Value Explanation
V current voltage
„0:00“ Power on time
mAh Capacity used in actual power on time
„0“ Satellites position number
km/h Average speed over ground as relieved
by GPS system
Alt current altitude
Dir Direction
I Actual current
m Distance from start as relieved by GPS
system
° Position in degreeses related to start as
relieved by GPS system
In the blank in the above figure line of the display any
messages Mikrokoptersensors display.
BAT 1
0.0V
0.0A
0mAh
This display depicts current voltage, current current
draw and, if attached, the expended capacity of “Batt
1” connected to the Electric-Air module (No. 33620).
