m
m
s
If attached, this display will depict altitude relative to
location or starting location (in m) as well as the cur-
rent rate of ascent/decent (in m/s) from data acquired
by a Vario module (No. 33601).
Text display
Subject to availability of the sensors, its text can be
displayed in the following two displays if necessary
with 2 x 10 or 3 x 7 signs:
VARIO
RX–S QUA: 100%
RX–S ST : 100%
TX–dBm: 33dBm
RX–dBm: 33dBm
RX–SPG.:4.8 TMP
V–PACK: 10ms
CH OUTPUT TYPE:ONCE
RECEIVER
GENERAL
ELECT. AIR
VARIO
GPS
RXSQ
0
MAX
0m
MIN
0m
ALT
0
H
L
m/1s
0.0
m/3s
0.0
m/10s
0.0
If attached to the receiver, this display will depict the
data acquired by a Vario module, No. 33601.
The displayed items are as follows:
Value Explanation
ALT current altitude
RXSQ Signal quality of the signal received by
the receiver in %, see page 241.
MAX the preset maximum altitude limit
relative to starting location at which,
when exceeded, will cause an audible
warning to be sounded
MIN the preset minimum altitude limit
relative to the starting location at which,
when underrun, will cause an audible
warning to be sounded
m/1s m/1 s ascent/decent rate
m/3s m/3 s ascent/decent rate
m/10s m/10 s ascent/decent rate
Micro-copter display
0mAh
0:00
0.0V
0km/h
0
I:
Dir:
Alt: 0m
0°
0A
0m
0°
This display visualizes the data of an HoTT compat-
ible microcopter. It means from left up to right down:
Value Explanation
V current voltage
„0:00“ Power on time
mAh Capacity used in actual power on time
„0“ Satellites position number
km/h Average speed over ground as relieved
by GPS system
Alt current altitude
Dir Direction
I Actual current
m Distance from start as relieved by GPS
system
° Position in degreeses related to start as
relieved by GPS system
In the blank in the above figure line of the display any
messages Microcopter sensors display.
