User Manual corpuls
3
Data Management
ENG - Version 2.1 – P/N 04130.2 187
8.2 Event Key
The corpuls
3
has an event key located in the top left-hand corner of the
monitoring unit.
When the Event key is pressed, a time stamp is saved which marks the current
ECG data and parameter values. On the basis of this marking, this data can be
located, viewed and assessed in the data memory.
If the audio recording option is enabled, a 15 second recording of the
surrounding sounds can be saved additionally by pressing the Event key (5 s
before and 10 s after pressing the key). The audio recording appears as manual
event in the protocol. Furthermore, by enabling the screenshot option, a screen
copy at the time of the event can be saved as a picture file. The audio
recordings and screenshots can be played and viewed with the software
corView2 (see chapter 8.6 Analysis of the Data with corView2, page 193).
8.3 Handling Data
The CompactFlash
®
card of the patient box is the central memory location for all
recorded data.
Insert the CompactFlash
®
card with the corpuls
3
label (incl. memory capacity)
facing towards the user and following the direction of the arrows into the card
slot at the left-hand side (seen from the front) of the patient box. If necessary,
remove the accessory bag.
If the CompactFlash
®
card is full (1000 missions or more) or not inserted into
the patient box, the corpuls
3
cannot record either a long-term ECG or a
diagnostic ECG. Consequently, these data are missing when a log is created.
The current date and time of the mission have to be deposited in the corpuls
3
to enable a later allocation of mission data.
Caution
Make sure that only an original corpuls
3
CompactFlash
®
card (P/N 04236.3)
with sufficient memory capacity is used (minimum 50 MB, if voice recording is
disabled).
Using other CompactFlash
®
cards may result in safety-critical system
malfunctions or the voiding of warranty.
Save the contents of the CompactFlash
®
card to a PC at regular intervals on
external storage media.
If the alarm message “CF-card error” is displayed, the data should be saved on
a computer. Then, the CF card must be re-formatted (see chapter 7.4.2 General
System Settings (Person responsible for the device)page 160).
Caution
Never insert or remove the CompactFlash
®
during the mission. This may result
in system errors.
Only insert or remove the CompactFlash
®
card when the patient box is
switched off.
and screenshots
