GS corpuls3 - Oximetry

Configuration User Manual corpuls
3
150 ENG - Version 2.1 – P/N 04130.2
7.2.2 Oximetry
1. In the main menu, select "Oximetry" ► "Settings".
The configuration dialogue opens.
Fig. 7-10 Settings for oximetry monitoring
2. Select the settings.
Table 7-6 contains the possible values.
Field Setting Values Increment
Curve
Sweep speed
12.5 mm/s,
25 mm/s, 50 mm/s
–
Auto Curve Enabled, disabled –
Pulse tone
Enabled Enabled, disabled -
Dynamic Enabled, disabled -
Volume 3 to 10 1
Puls tone 1 to 4
Mode
FastSat Enabled, disabled –
Averaging
2-4 s, 4-6 s,
8 s to 16 s
–
2
Sensitivity Max., Norm, APOD –
SpHb Unit g/dl, mmol/l –
Table
7-6 Values for oximetry Monitoring
Settings
