GS corpuls3 - Insurance Card Reader (Option)

Data Management User Manual corpuls
3
202 ENG - Version 2.1 – P/N 04130.2
If a connection to an external documentation system has been established via
the Bluetooth® data interface, the symbol for „Bluetooth® connection“ is
displayed in the status line.
Depending on the status there are additional markings of the above described
symbols for telemetry connections. A detailed description can be found in
Appendix A Symbols, page 272.
If the Bluetooth® connection is interrupted for technical reasons (e.g. insufficient
reception quality or interruption of the radio connection) the alarm message “BT
connection failed“ is displayed. In case of malfunctions see also
chapter 10.2 Troubleshooting and Corrective Actions, page 250.
To abort the current Bluetooth
®
connection, select „Bluetooth“ ►
„Disconnect“ with the jog dial in the main menu.
The protocol records status messages of the Bluetooth
®
connection as event.
For information on possible events see chapter 10.3 Notifications Message Line
and Information in the Protocol, page 263.
8.10 Insurance card reader (option)
The insurance card reader allows to read out the patient data stored on the
insurance cardof the patient so that they are available to the data management
in the corpuls
3
.
The patient data can be completed or changed during the mission by manually
entering information. Persons responsible for the device can configure and save
permanently which patient data from the insurance card should be available in
the corpuls
3
(see chapter 7.4.12 Data Protection Settings (Persons
responsible for the device) , page 182).
1. Insert the insurance card (with the chip oriented towards the front of the
monitoring unit) into the insurance card reader on the right-hand side of the
monitoring unit
Interrupting a
Bluetooth
®
connection
Bluetooth
®
connection failed
Symbol
Bluetooth® Data
interface
