User Manual corpuls
3
Operation – Monitoring and Diagnosis
ENG - Version 2.1 – P/N 04130.2 131
6.7.4 Performing Blood Pressure Interval Monitoring
Warning
Make sure that the blood circulation is not impaired in the extremity to which
the NIBP cuff is attached.
Set the time value for interval monitoring (see chapter 7.4.14 Configuration of
Non-Invasive Blood Pressure Measurement (NIBP) (Persons Responsible for
the Device), page 184). This pre-configured value is shown by default on the
NIBP user surface and can be changed by pressing the softkey [Interv.].
1. In monitoring mode press the softkey [NIBP].
2. Press the softkey [Mode] repeatedly until the required mode "Adult“, "Child"
or "Neonate" appears.
3. Press the softkey [Auto]. The softkey [Auto] remains selected.
4. Change the interval with the softkey [Interv.] or leave at default value.
5. To start an interval measurement press the softkey [Start] .
As soon as the interval measurement has been started, a clock symbol
alternates with the alarm symbol in the upper right corner of the NIBP
parameter field. The clock symbol indicates that the interval measurement
is active and that an automatic measurement is being prepared
Above the softkey [Auto], a countdown shows the remaining time until the
next interval measurement.
6. To quit the interval measurement, press the softkey [Auto]. A measurement
in progress can be interrupted with the softkey [Stop].
If the NIBP measurement is interrupted, the inscription above the softkey [Auto]
shows four dashes instead. The pressure in the NIBP cuff is then released
immediately.
Open the NIBP user surface to see if interval measurement is active.
During the interval measurement it is now possible to perform an individual
measurement manually at any time between two automatic interval
measurements by pressing the softkey [Start].
6.8 Invasive Blood Pressure Monitoring (Option)
6.8.1 Information on IBP Monitoring
With the IBP function, various pressures can be measured within the context of
intensive medical care. This includes, among others, arterial pressure, central
venous pressure or intracranial pressure.
Two interfaces are available which can be assigned as single channels or as
double channels, respectively. For usage as a double channel, an IBP_Y-
adapter cable is needed (in preparation). Consequently, up to four different
invasive pressure measurements can be performed simultaneously. The
recorded pressure values can be displayed on the screen either as numerical
parameters and/or as an evolution curve.
