5.7.2 Preparing CPR Feedback
How to handle the corPatch CPR sensor is described in the following.
1. Connect the corPatch CPR sensor (item 1) to the corPatch CPR
intermediate cable (item 2) leading to the patient box.
Fig. 5-17 Connecting the corPatch CPR sensor to the corPatch CPR
intermediate cable
2. Tear open the package of the corPatch CPR sensor along the markings.
3. Remove the protective foil from the corPatch CPR sensor, so that the
corPatch CPR sensor can be attached to the patient's thorax as shown in
the illustration.
Fig. 5-18 CPR feedback, attaching the corPatch CPR sensor
