Precision of the Energy Released
selected
energy in
Joules
Nominal energy released in comparison
to patient impedance
Precision
Load impedance (in Ohm)
25
50
75
100
125
150
175
2
1.9
2.3
2.2
2.3
2.3
2.1
2.0
± 3J
3
2.8
3.3
3.4
3.1
3.0
2.8
2.8
± 3J
4
3.9
4.4
4.4
4.2
4.0
3.8
3.5
± 3J
5
5.1
5.5
5.3
5.3
4.8
4.6
4.3
± 3J
10
9.5
10.6
10.5
10.1
9.8
9.4
8.8
± 3J
15
15
17
16
16
15
14
13
± 3J
20
20
22
21
20
20
18
18
± 15%
25
24
27
26
25
24
23
22
± 15%
30
29
32
31
30
29
27
26
± 15%
35
33
37
36
35
33
31
30
± 15%
40
37
42
40
39
37
35
33
± 15%
45
42
47
46
44
42
40
37
± 15%
50
46
52
51
49
46
44
42
± 15%
55
51
57
55
53
50
48
46
± 15%
60
56
61
60
58
55
52
49
± 15%
65
60
67
66
63
59
56
53
± 15%
70
65
72
70
68
65
61
58
± 15%
75
69
77
75
72
69
64
61
± 15%
80
73
81
80
77
73
69
65
± 15%
85
78
86
85
82
78
74
70
± 15%
90
82
92
90
87
82
77
74
± 15%
95
87
96
95
91
86
81
77
± 15%
100
91
101
99
96
91
86
82
± 15%
105
95
107
105
101
96
90
85
± 15%
110
101
111
110
106
100
93
89
± 15%
115
104
116
115
111
106
99
94
± 15%
120
108
120
119
115
109
102
96
± 15%
125
113
125
124
120
114
107
102
± 15%
130
117
130
129
124
118
111
105
± 15%
135
122
135
134
130
123
116
109
± 15%
140
126
139
139
134
127
119
111
± 15%
145
130
145
145
140
131
123
117
± 15%
150
135
149
149
144
136
129
121
± 15%
155
138
154
153
148
140
132
125
± 15%
160
143
159
158
154
145
136
128
± 15%
165
147
164
163
159
148
140
133
± 15%
170
150
169
168
162
154
143
136
± 15%
175
154
174
173
168
159
149
140
± 15%
180
158
179
178
172
163
151
144
± 15%
185
161
183
182
177
167
156
147
± 15%
190
165
188
187
181
171
160
152
± 15%
195
167
194
193
186
176
165
155
± 15%
200
168
199
197
192
181
170
161
± 15%
Table A-31 Precision of the energy released
