IconMaster Installation and Configuration Manual 139
Chapter 7: Automation Setup
Source Configuration in src.tbl
The internal logo store of the IconMaster (associated with keyers 3-6) can be
controlled as a source by D-MAS. This allows D-MAS to control which internal
logo is associated with each of these keyers. If no source control is configured
for a particular internal keyer, then that keyer displays whatever logo was last
configured manually.
Operation Notes
When the corresponding source entry is specified in the appropriate subevent,
the corresponding material ID field accepts numeric entries between 1 and 999
to specify an internal logo from the IconMaster logo store (there is no checking
to ensure a specific logo number actually exists).
At the ready time, a request is issued to load the specified logo number, unless
the keyer is already active on the IconMaster’s PGM bus (in which case, the
logo is not loaded until start time).
Configuration for Squeezeback and DVE Effects
The IconMaster supports up to 16 squeezebacks or DVE effects that are
preconfigured (i.e. the details of the effect can not be controlled from D-MAS).
DVE transitions are not supported.
Currently, only a single upstream router may be defined for the
IconMaster. Thus, if an IconMaster is using explicit routing for both
program and effect sources, the program and effect sources must
be on the same upstream router.
Table 7-4. Settings in src.tbl for IconMaster Internal Logo Store Sources
(Keyers 3-6)
Field Value
Switcher number Index of the IconMaster entry in swr.tbl
Main source main audio input number 1
Main source main video input number 1
Source Type Source type associated with a specific
sub-event used to map source to a keyer
(normally one of D1, D2, D3, D4, L1 or
L2). This should match the setting for
corresponding “Switcher level n” entry
for the keyer in swr.tbl (where n=3, 4, 5
or 6).
Machine control type ICM
Machine control index Index of the IconMaster entry in swr.tbl
Default control number 11 (i.e. ready and start control)
Ready time A suitable time (a few seconds is ample)
