IconMaster Installation and Configuration Manual 181
Chapter 8: Configuring IconMaster
Figure 8-19. Transitions Quick Select Dialog Box
By selecting a Transition check box, you recall the state of the transition
settings, as described in Table 8-6.
Click Select All to enable all transition features for that quick select. Click
Select All again to unselect all transition features for that Quick Select.
If Auto Take is selected, when the Quick Select is recalled to the PST, and a
take is activated to send the PST content to the PGM. The previously shown
PST content is not preserved. If Auto Take is not selected, you can achieve the
same effect by pressing Take on the Control Panel.
A breakaway transition cannot be saved in a Quick Select.
Table 8-6. Quick Selects Options for Transitions
Quick Select Option
Background Transition Saves and recalls the state of the BKGD button on
the control panel
Background Source The source that is on the Preset bus (whether the
background is on or off)
Effects All effects that are set on the transition
Transition Rate The preset duration for transitions
Transition Type The shape of the transition
