16 IconMaster Installation and Configuration Manual
Chapter 2: Installation
Scenario 9: Audio Control Panel Ordered Separately, Optional Modules
Ordered Separately; External Router
Step Explained
1. Connect main control panel to audio control panel
page 21
2. Mount the control panel(s) into a desktop or a rack
page 23
3. Connect the control panel to another device
page 28
4. Install NEO options into NEO frame
page 35
5. Install NEO frame into a rack
page 37
6. Mount external router into a rack (see specific router manual)
7. Configure external router
Panacea
Platinum
page 91
page 116
8. Attach breakout modules
page 43
9. Connect the NEO modules to another device
page 38
10. Check card-edge parameters are set to your preferences
page 69
11. Initialize IconMaster
page 126
12. Configure IconMaster control panel
page 147
13. Customize push buttons on control panel
page 63
Scenario 10: Audio Control Panel Ordered Separately, Optional Modules
Ordered Separately; Platinum Router, CENTRIO, eBox
Step Explained
1. Connect main control panel to audio control panel
page 21
2. Mount the control panel(s) into a desktop or a rack
page 23
3. Connect the control panel to another device
page 28
4. Install NEO options into NEO frame
page 35
5. Install NEO frame into a rack
page 37
6. Install CENTRIO into Platinum router (see CENTRIO Installation,
Configuration, and Operation Manual)
7. Mount Platinum router into a rack (See Platinum Installation,
configuration, and Operation Manual)
8. Configure eBox
page 121
9. Configure Platinum
page 116
10. Configure CENTRIO
page 121
11. Attach breakout modules
page 43
12. Connect the NEO modules to another device
page 38
13. Check card-edge parameters are set to your preferences
page 69
