Hioki PQ3100 User Manual

129
11
Analysis (with Computer)
This section describes how to load data recorded with the instrument onto a computer and analyze
the data using the supplied application software, PQ One.
Refer to Application Software Instruction Manual (CD).
Recording data
Included application software
File contents Extension Format
Supported software
Application
software
Other than application
software
Screen copy data BMP Binary — Graphics software
Setting data SET Binary

—
Trend record data ITV Binary

Flicker/trend record data
(Available after the rmware
update)
FLC Binary

Event list EVL Binary

Event data EVT Binary

Event trend data WDU Binary


: Supported, —: Not supported
The data measured by the instrument is written in binary format and cannot be directly read using spreadsheet
software such as Microsoft Excel
®
. When the measured data is read using the appropriate application software
and output in CSV format, the data can be read using spreadsheet software (available after the rmware
update).
11.1 Copying Files
The following methods are available to copy data saved to a computer.
Method
SD
memory
card
Internal
memory
Reference
Use an SD memory card reader

— p. 130
The SD memory card is recognized as a removable disk by
connecting the instrument to a computer with a USB cable

— p. 131
Copy the data from the internal memory to the SD memory
card and copy the data from the SD memory card
—

p. 125

: Supported, —: Not supported
11 Analysis (with Computer)
11
Analysis (with Computer)
