Hioki PQ3100 User Manual

27
Screen Conguration
EVENT screen
A screen used to check the event status.
Display/switch screen: [EVENT] key
See “9 Checking Events (EVENT Screen)” (p. 105).
Event list screen
Events can be checked on the list.
The events are sorted in the order of
occurrence.
Event statistics screen
(available after the rmware update)
This screen is used to check the statistical
results for each event type.
EVENT MONITOR screen: See p. 111.
WIRING screen
A screen used to check the wiring settings.
Display/switch screen: [WIRING] key
See “4 Wiring (WIRING Screen)” (p. 47).
Wiring settings screen
This screen is used to congure the wiring.
Make wiring by checking the wiring diagram.
Wiring check screen
This screen is used to check whether the
instrument has been connected properly.
