Interface Specications
14.6 Interface Specications
1. SD memory card
Slot SD standard compliant × 1
Compatible card SD memory card/ SDHC memory card (Use only Hioki-approved card)
Format SD memory card format
Supported memory
capacity
SD memory card: up to 2 GB
SDHC memory card: up to 32 GB
Functions Save and read the following content:
• Binary data (measurement data)
• Settings le
• Screen copy (save only)
Deleting of les
Format
2. LAN interface
Connector RJ-45 × 1
Electrical specications IEEE802.3 compliant
Transmission method 100BASE-TX
Protocol TCP/IP
Functions HTTP server function (Compatible software: Internet Explorer Ver. 9 or later)
Remote control application function
Recording Start and End control function
Conguration Function
Event list function (capable of displaying event waveforms, event vectors, and event
harmonic bar graphs)
Settings according to the communication commands, acquisition of measurement data,
and data download
3. USB interface
Connector Series B receptacle × 1
Method USB 2.0 (full-speed, high-speed), mass storage, class
Connection destination Computer: Windows 7 (32-bit/64-bit) or Windows 10 (32-bit/64-bit)
Functions When connected to the computer, the computer recognizes the SD memory card to be
a removable disk, and downloads the data from the SD memory card.
Note: The instrument cannot be connected while recording (including standby).
