Hioki PQ3100 User Manual

2
Verifying Package Contents
Verifying Package Contents
When you receive the instrument, inspect it carefully to ensure that no damage occurred during
shipping. In particular, check the accessories, keys, switch, and connectors. If damage is evident,
or if it fails to operate according to the specications, contact your authorized Hioki distributor or
reseller.
Check that the package contents are correct.
PQ3100 Power Quality Analyzer
× 1
Accessories
L1000-05 Voltage Cord
Maximum rated voltage: 1000 V, maximum rated current: 10 A
Alligator clips (black, red, yellow, blue, gray)
3 m banana plug leads (black, red, yellow, blue, gray)
Spiral Tubes (Cord bundling)
See “Bundling the voltage cords and current sensors (If required)”
(p. 37), “Connecting Voltage Cords to Instrument” (p. 51), and
“Connecting Voltage Cords to Objects” (p. 55).
×1 each
×1 each
×5
Z1002 AC Adapter (with power cord)
×1
Z1003 Battery Pack
×1
USB cable
×1
Colored spiral tubes in red, yellow, and blue (color coding for
current sensors)
×2 each
Spiral tubes in black (cord bundling for current sensors)
×5
Strap
See “Attaching the strap (if required)” (p. 39).
×1
Instruction Manual*
×1
Measurement Guide*
×1
CD (computer application software)
See “11.2 Use of Application Software PQ One (Included)” (p. 133).
The latest version can be downloaded from our website.
×1
*: See Hioki website for other languages.
Precautions when transporting the instrument
Handle the instrument carefully so that it is not damaged due to a vibration or shock.
