Wiring (WIRING Screen)
4.1 Wiring Procedure
Connect the voltage codes and the current sensors to the instrument according to the following
procedure.
This chapter explains the procedure for wiring without using the Quick Set.
Setting the wiring method and the declared input voltage
“4.2 Wiring Method and Declared Input Voltage Settings” (p. 48)
Connecting the cords and the sensors and
performing the zero adjustment
“4.3 Connecting Voltage Cords to Instrument” (p. 51)
“4.4 Connecting Current Sensors and Conguring Current Sensor Settings” (p. 52)
“4.5 Zero Adjustment” (p. 54)
Connecting the voltage cords to the measuring object
“4.6 Connecting Voltage Cords to Objects” (p. 55)
Attaching the current sensor to the measuring object
“4.7 Attaching Current Sensors to Objects” (p. 56)
Checking the wiring
“4.9 Checking Wiring” (p. 59)
4 Wiring (WIRING Screen)
4
Wiring (WIRING Screen)
