98
Verifying the Basic Trend
8.1 Verifying the Basic Trend
Press the [TREND] key to display the TREND, Basic trend screen.
This screen is used to check uctuation width of maximum, minimum and average values between
recording intervals.
(The maximum, minimum, and average values are calculated incessantly after every 200 ms.)
1 52 3
MAX: Maximum value
AVG: Average value
MIN: Minimum value
The latest measured values are displayed
when the cursor is disabled, while the
measured values at the position of
cursor are displayed during the cursor
measurement.
(The gure on the left illustrates the
screen that is displayed when the cursor
is disabled.)
4
Move the cursor
Select
To Next Page
