Hioki PQ3100 User Manual

75
System Settings
5.4 System Settings
Press the [SET UP] key to display the SET UP, System settings screen.
1
Serial number of this instrument
Software version of this instrument
FPGA version of this instrument
2
3
4
5
6
Move the cursor Select
1
Enables you to set the date and time.
(The seconds cannot be set. If you press the [Enter] key after changing the value, the seconds will
be set to 00.)
2
Select ON to enable a beep sound when pressing a key.
ON, OFF
3
Enables you to select whether or not to auto-off the backlight of the display.
Auto OFF
The backlight automatically turns off after 2 min have elapsed since the last
key operation.
ON The backlight is on at all times.
4
Enables you to select the display language.
Japanese German
English French
Chinese Simple (Simplied) Italian
Chinese Trad (Traditional) Spanish
Korean Turkish
5
Enables you to select the display color.
Color 1, color 2, color 3
6
Enables you to select the phase names for the measuring objects displayed on the wiring diagram.
RST, ABC, L1L2L3, UVW
5
Setting Change (SET UP Screen)
