Screen Conguration
TREND screen
A screen used to check the trend (uctuations) of the measured values.
Display/switch screen: [TREND] key
See “8 Verifying the Trends (Fluctuations) in Measured Values (TREND Screen)” (p. 95).
Basic trend screen
This screen is used to check uctuation
width of maximum, minimum and average
values between recording intervals.
Detail trend screen
This screen is used to check uctuation width of
maximum and minimum values between recording
intervals for the following parameters.
• RMS voltage refreshed each half-cycle
• RMS current refreshed each half-cycle
• Inrush current
• Frequency (1 wave)
Electric energy screen
This screen is used to check electric energy trends for
each recording interval.
Demand screen (available after the rmware
update)
This screen is used to check demand trends.
Harmonics trend screen (available after the
rmware update)
This screen is used to check trends of harmonics and
interharmonics.
Flicker screen (available after the rmware
update)
This screen is used to check trends of IEC icker or
∆V10 icker.
