Hioki PQ3100 User Manual

37
Initial Measurement Preparations
Bundling the voltage cords and current sensors (If required)
Be sure to read “Handling Cords and Cables” (p. 8), “Using Voltage Cords” (p. 8).
If required, group the cables together by using the spiral tubes (black).
Example: In the case of using 3 voltage cords and 2 current sensors
Required items

Spiral tubes (for grouping the cables together)
Black (thick) ×10

Current sensor in use ×2
(The model illustrated above is
Model CT7136)

Model L1000-05 Voltage Cord ×3
Black
Red
Yellow
CH1 Red
N Black
CH2 Yellow
Red
Black
Yellow
CH1 Red
CH2 Yellow
Red
Yellow
Model L1000-05 Voltage Cord Current sensor
2
Preparing for Measurement
