43

Power Supply

2.5 Power Supply

Be sure to read “Using AC Adapter” (p. 11).

Required items



Model Z1002 AC adapter

(AC adapter + power cord)

Power OFF

1

Power cord

AC adapter

Connect

2

Connect

3

Connect

5

Hook

4

2

Preparing for Measurement
