Hioki PQ3100 User Manual

78
System Settings
Factory settings
All the default settings are as follows:
*1: Checked parameters (

) are the parameters that are not initialized in quick set.
*2: Checked parameters (

) are the parameters that are not initialized during the system reset.
These are initialized in the factory reset only.
Screens items Default values *1 *2
Measurement
settings 1
Wiring Display Language:
Japanese
CH123: 3P3W2M
CH4: OFF
Display language:
Other than above
CH123: 3P4W
CH4: ON
Declared input voltage Display Language:
Japanese
200V
Display language:
Other than above
230V
VT ratio CH123: 1
CH4: 1
Current sensor CH123: CT7136
CH4: CT7136
Current range CH123: 500 A
CH4: 500 A
CT ratio CH123: 1
CH4 :1
Measurement
frequency
Select 50 Hz or 60 Hz after the factory reset.
 
Measurement
settings 2
Urms Other than 3P3W: Phase voltage
3P3W: Line voltage
PF/Q/S RMS value
THD THD-F
Harmonics
(Available after the
rmware update)
U, I, P: All levels
Energy unit cost 0000.00/kWh
Energy cost currency _____
Flicker
(Available after the
rmware update)
Display Language:
Japanese
∆V10
 
Display language:
Other than above
Pst,Plt
Filter
(Available after the
rmware update)
Display Language:
Japanese
-
 
Display language:
Other than above
230V lamp
Recording
settings
Recording interval 1min
Recording items Yes harmonic
Screen save OFF
Recording start method Interval time
Recording stop method Manual
Folder/ File name Automatic
