System Settings
Screens items Default values *1 *2
Event settings 1 Transient CH123: OFF
CH4: OFF
Swell OFF
Dip OFF
Interruption OFF
Frequency (200 ms) OFF
Frequency (1 wave) OFF
Voltage total harmonic
distortion
OFF
Inrush current CH123: OFF
CH4: OFF
Current total harmonic
distortion
CH123: OFF
CH4: OFF
Hysteresis 1%
Event settings 2 Timer event OFF
External event OFF
Event waveform
recording time
Before event occurs
OFF
Event waveform
recording time
After event occurs
OFF
System settings Clock Set at the time of shipment
 
Beep sound ON

LCD backlight Auto OFF

Display language Language selection after factory reset
 
Display color Color 1

Phase name Display Language:
Japanese
RST
 
Display language:
Other than above
ABC
Interface
settings
DHCP (available after the
rmware update)
OFF
 
IP address 192.168.1.31
 
Subnet mask 255.255.255.0
 
Default gateway 192.168.1.1
 
FTP function
(Available after the
rmware update)
Undetermined
 
Send mail
(Available after the
rmware update)
Undetermined
 
RS-232C baud rate 19,200bps
 
External output Short pulse
 
5
Setting Change (SET UP Screen)
